GARANT BR
The general purpose electrode Garant BR is suited for assembly and repair welding of unalloyed and low-alloyed steels in industry and craft. In particular, it provides good welding properties in constrained positions and with AC current.
Standards:
| DIN EN ISO 2560-A | E 38 2 B 32 H10 |
| AWS A 5.1 | E 7016 |
| Construction steel | S235 to S355 |
| Ship steel | A32/36, D32/36, E32/36, A40, D40, E40 |
| Fine-Grained steel | S275 to S355 |
| Pressure tank steel | P195 to P355 |
| Pipe steel | L210 to L360 |
| Cast steel | GE200, GE240, GP240, G21 Mn5 |
| Reinforcing steel | BSt 420, BSt 500 |
| Type of current | AC DC plus pole |
||
| Diameter | 2.5 mm 3.25 mm 4.0 mm |
||
| Weld Metal Composition | C | Si | Mn |
| 0.07 % | 0.3 % | 0.6 % | |
